Ek 520 Mvxz2 Drive Chain

The EK 520 MVXZ2 Drive Chain is engineered for maximum performance and durability, making it an ideal upgrade for both street and off-road motorcycles. This high-performance chain ensures reliable power transfer and extended wear life, letting you push your bike to its limits.

Description

EK's 520 MVXZ2 Drive Chain utilizes a Quadra-X ring design to significantly reduce friction and increase wear life by up to 40%. This innovative design maximizes engine performance and ensures smooth, efficient operation. Featuring Zero Stretch Technology, the MVXZ2 eliminates measurable chain stretch during the first 965.6 km (600 miles) of use, providing consistent performance from the start. Lightening holes in the side plates and large-diameter pins further enhance the chain's strength and reduce weight. This 520 drive chain is suitable for off-road bikes up to 750cc and street bikes up to 1000cc.

Features & highlights

• Quadra-X ring design minimizes friction and maximizes wear life, boosting overall engine performance.
• Zero Stretch Technology ensures consistent performance by eliminating measurable stretch during the initial break-in period.
• Lightening holes in side plates reduce weight without compromising strength.
• Large-diameter pins enhance the chain's overall durability and resistance to wear.
• Suitable for high-performance street and off-road motorcycles.
• Gold finish provides enhanced corrosion resistance and looks great.

Technical specifications

• Brand: EK
• Chain Size: 520
• Chain Type: 520 MVXZ2
• Color/Finish: Gold
• Master Link Connector Type: Rivet
• Material: Steel
• Maximum Engine Displacement (Offroad): 750 cc
• Maximum Engine Displacement (Street): 1000 cc
• Number of Links: 120
• Seal Type: X-Ring
• Tensile Strength: 40 kN (8995 lb)
• Weight: 1.76 kg/100 Links

Important to know

This MVXZ2 chain includes a rivet connecting link. Professional installation is recommended for optimal performance and safety.
