Koso D60-HD TNT-05 Speedometer - km/h & mph - BA085004

The Koso North America D60-HD TNT-05 Speedometer is a compact, multi-functional gauge designed to provide riders with comprehensive information at a glance. This unit combines an analog speedometer with a suite of digital readouts, ensuring you have all the essential data you need for a safe and informed ride. Monitor your speed, temperature, fuel level, and more with this all-in-one instrument.

Description

The Koso D60-HD TNT-05 Speedometer offers a wide range of functions, including speedometer, odometer, trip meter, temperature gauge, fuel meter, voltmeter, and clock. The analog speedometer displays speeds from 0 to 160 km/h (or mph), while the digital display provides precise readings and additional data. Customize the backlight with seven user-selectable colors to match your bike's aesthetics or improve visibility. The integrated warning lights alert you to critical conditions such as speeding, low fuel, low voltage, and overheating. With its compact 60 mm diameter, this speedometer is easy to install and integrates seamlessly into any motorcycle setup. Whether you're a daily commuter or a weekend rider, the Koso D60-HD provides the essential information you need for a confident and enjoyable ride. Take control of your ride with the advanced features and reliable performance of the Koso D60-HD TNT-05 Speedometer.

Features & highlights

• All-in-one design integrates speedometer, odometer, trip meter, temperature gauge, fuel meter, voltmeter, and clock.
• Analog speedometer displays speeds from 0 to 160 km/h (mph) with precise digital readouts.
• Seven user-selectable backlight colors for personalized aesthetics and enhanced visibility.
• Integrated warning lights for speeding, low fuel, low voltage, and overheating.
• Compact 60 mm diameter for easy installation and seamless integration.
• Displays critical data to ensure safe and informed riding.

Technical specifications

• Brand: Koso North America
• Part Number: 22110204
• Speedometer Range: 0 - 160 km/h (mph)
• Temperature Display Range: 0.0 - 250.0 °C (32.0 - 482.0 °F)
• Voltmeter Display Range: DC 8.0 - 18.0 V
• Fuel Gauge Setting Range: 100 O, 250 O, 270 O, 390 O, 510 O, 1200 O, Sw, Custom(learning mode), OFF
• Operating Voltage: DC 12V
• Operating Temperature: -10 - +60 °C
• Storage Temperature: -20 - +80 °C
• Meter Diameter: 60 mm (2.36")

Important to know

This speedometer requires a 12V DC power source for operation. Ensure proper wiring and connections during installation. Please refer to the included installation manual for detailed instructions and safety guidelines.
