Legend Suspension REVO-A Shocks - 12" - Black - 1310-0956

Upgrade your V-Rod's suspension with the Legend Suspension REVO-A coil suspension. Designed for superior ride quality and performance, this adjustable coil suspension system offers enhanced control and a plush ride. Built with high-quality materials and advanced damping technology, the REVO-A ensures a smooth and comfortable riding experience.

Description

The Legend Suspension REVO-A adjustable coil suspension is engineered to provide exceptional performance and ride quality for V-Rod motorcycles. Featuring touring-specific spring rates, this system delivers improved control, resistance to bottoming out, and a plush ride feel. The extended coil length maximizes the "sweet spot" without increasing overall shock length, while the unique spring rate allows for softened preload or reduced ride height while maintaining a smooth ride. Adjusting preload is easy and tool-free, accommodating changes in rider weight or total motorcycle load. The hard-anodized machined aluminum body, low-friction seals, and high-flow piston ensure durability and responsive fluid flow management. Deflective disc valved damping self-adjusts to frequency for controlled performance. Spherical mount bearings are located on the top and bottom for smooth articulation. With six external knob adjustments for fine-tuning rebound damping, riders can optimize rebound performance for any weight, riding style, or personal preference. Available in standard or heavy-duty spring rates, heavy-duty applications are recommended for riders with a combined weight of 250 lbs or more.

Features & highlights

• Experience superior ride quality and performance with Legend’s touring-specific spring rates.
• Enjoy improved plush ride quality, control, and resistance to bottoming out.
• Maximize performance with the extended coil length's larger "sweet spot".
• Easily adjust preload by hand without tools for changing rider weight or motorcycle load.
• Benefit from the durability of the hard anodized machined aluminum body and Legend’s low-friction seals.
• Fine-tune rebound damping with six external knob adjustments for personalized ride quality.
• Ensure controlled performance with deflective disc valved damping that self-adjusts to frequency.

Technical specifications

• Brand: Legend Suspension
• Product Name: Shock Absorber
• Type: Coilover Twin-Tube
• Mounting Position: Rear
• Adjustment Type: Adjustable Rebound Damping
• Extended Length: 305.00 mm (12.00")
• Material: Aluminum
• Color/Finish: Black, Anodized
• Duty: Heavy Duty
• Reservoir Location: Internal
• Units: Pair

Important to know

Heavy-duty applications are recommended for 250 lb. + rider and passenger total weight.
