S&S Cycle M8 475C Cam Chest Kit - Chrome - 310-1000B

Upgrade your Milwaukee-Eight engine with the S&S Cycle Cam Chest Kit. This comprehensive kit delivers enhanced performance, reliability, and durability, making it an ideal choice for both performance enthusiasts and professional builders.

Description

The S&S Cycle Cam Chest Kit for M8 engines is engineered to optimize oil flow and improve valvetrain stability. At the heart of this kit is a precision-machined billet aluminum oil pump and cam plate, featuring a blue anodized finish for enhanced corrosion resistance and aesthetics. Independent scavenge sections for the flywheel cavity and cam chest ensure efficient oil return, while debris screens and a strategically placed magnet prevent contaminants from circulating through the engine. The adjustable pressure relief valve, accessible even when installed, allows for fine-tuning of oil pressure. The kit includes S&S high-performance cam chain tensioners, Quickee pushrods, and S&S precision tappets, contributing to smoother and more reliable engine operation. The billet aluminum tappet cuffs with a hard anodized black coating provide increased tappet stability, especially in high-lift and high-RPM conditions. All necessary gaskets, bearings, and hardware are included for a straightforward installation. Made in the USA.

Features & highlights

• Precision-machined billet aluminum oil pump and cam plate with blue anodized finish.
• Independent scavenge sections for superior oil return from the flywheel cavity and cam chest.
• Debris screens and magnet to protect the oil pump from harmful contaminants.
• Adjustable pressure relief valve for fine-tuning oil pressure.
• Includes S&S high-performance cam chain tensioners for improved reliability.
• Billet aluminum tappet cuffs with hard anodized coating for enhanced tappet stability.
• Complete kit includes all necessary gaskets, bearings, and hardware for installation.

Technical specifications

• Brand: S&S Cycle
• Product Name: Cam Chest Kit
• Vendor Part Number: 310-1000B
• Application: Water Cooled
• Cam Grind: 475C
• Type: Chain
• Intake Open: 6.2° Front, 2.2° Rear
• Intake Close: 27.2° Front, 31.2° Rear
• Intake Duration: 213.5° Front, 213.5° Rear
• Intake Lift: 0.475"
• Intake Lift at TDC: 0.107" Front, 0.093" Rear
• Intake Lobe Centerline: 100.5° Front, 104.5° Rear
• Exhaust Open: 55.5° Front, 52.2° Rear
• Exhaust Close: 28.5° Front, 20.2° Rear
• Exhaust Duration: 263.9° Front, 252.5° Rear
• Exhaust Lift: 0.475"
• Exhaust Lift at TDC: 0.208" Front, 0.170" Rear
• Exhaust Lobe Centerline: 103.5° Front, 106.0° Rear
• Features: Chrome Pushrod Tubes

Important to know

This kit includes all necessary components for installation. Professional installation is recommended.
